home > products >Machine Model
  • description
  • specifications
  • size
  • detail
  • cloth kind
LXC-366S

Lianxing Computerized flat knitting machines are used digital technology to achieve the patterns of transfer, tuck, pointel, intarsia, jacquard, apparent shape, hidden shape and other regular pattern knitting functions, can knit basic single or double jersey plain fabric, irregular multi-colors jacquard, intarsia, cable and pointel structure patterns.
Knitting Area:Sweater,Scarf,Hat,Collar&Cuffs,Car seat,Shoes upper,Medical device,ballproof clothes,ect.

Brand


Gauge

LIANXING


5G,7G,8G,10G,12G,14G,16G and multi-gauge6.2G,

3-5-7G;

Knitting width

66" WEIGHT:ABOUT 1180-1280KGM

Knitting speed

Controlled by AC servo motor with 24 sections speed

optional, max 1.2m/s;

Knitting system

GE2:single carriage with three systems;

Knitting function

Knit, miss, tuck, transfer, pointelle, intarsia, jacquard,

hide,or apparent shaping and other regular patterns.

Racking system

Controlled by AC servo motor racking within 2 inches

and with fine micro adjustable function.

Encoder

Advanced encoder adopted.

Transfer cam

Combined type transfer cam, both single and double

system all can transfer separately or synchronously,

also can transfer by one system, knitting by another,

which will achieve high efficiency.

Stitch density



Controlled by stepping motor,24 sections density

selectable,adjustable

scope supported by subdivision technology:0-650,the

length of knitwear piece can be accurately controlled.

Sinker system

Controlled by stepping motor, adjustable to different

knitwear ,achieve various results of narrowing and

widening.

Comb and culter

(C series)

Adopting close_end U-shaped composite needles

which can hold and release yarns on the principle

that release freely.

Clip and cutter

(C series)

Including 4 clips and 2 cutters,controlled by 6 motors

separately.Program command can proceed simultaneously

or separately to further increase efficiency and reduce

waste of yarn.

Take down roller

Computerized, controlled by stepping motor,24 levels

selection of tension with adjustable scope:0-100.

Yarn feeder

2x8 yarn feeders on both sides of 1 guide rail of 4, switchover

on any position of needle bed (special intarsia yarn feeders

optional).

Protection system

The machine will automatically alarm if yarn-breaking, knots

floating, rewind, end of knitting, fail of racking, needle jack crash,

error programming occur, also with safety auto-lock

protection device.

Control system

1,LCD touch screen, graphical interface. USB and network

compatible, with   expanded memory of up to 1G. A great

amount of patterns can be stored and mobilized for use at

any time as per production requirements.

2,Monitoring display: Various operating parameters can be

displayed and can be adjusted anytime when the machine is

running, making operations as convenient and time-saving

as possible.

3,Design system and control system (softwares) are easy

to update for free.

4,Multi-language operating system:There are Chinese, English

and Arabic versions. Languages can be switched according to

customer requirements.

Power

Single-phase 220V/50HZ,1.5KW,adopt advanced CMOS technology enabling

memorizing at the instant of power outages and restoring of

knitting thereafter.
